0-10Mb/s 单模双纤光收发一体模块
0-10M/S TTL SINGLE MODE DUPLEX FIBERS OPTICAL TRANSCEIVER

特点:
● SC/FC/ST 或尾纤型光接口,单模双纤收发一体光模块
● +3.3V /+5V 供电
● 接口电平兼容标准 TTL 电平和 CMOS 电平
● 标准 1×9 管脚封装
● 发射器件可选用 1310nm FP LD
● 极低功耗设计,满足特殊要求
● 传输速率低至直流,上限速率可选,最高可达 10Mb/s

Feature:
● SC/FC/ST receptacle optical interface and pigtail optical interface
● Single mode Duplex fibers optical transceiver
● Standard +3.3V/ or +5V Power Supply
● Standard TTL data output with signal detect indication, compatible with CMOS level
● Standard 1×9 package
● Transmit as MQW 1310nm wavelength FP LD
● Super low power consumption, applied to some special requirement
● Optional transmission bit rate with down to 0bps and up to 10Mbps

应用:
● 适用于 10Mb/s 以下的电力控制和工业控制的 RS232、RS485 等光电转换设备。

Applications:
● Applied to RS232、RS485 optical-electrical converter for electric power control and industrial control with bit rate up to 10Mbps

 产品型号:FT-61-M324x-41

Important Notice

Performance figures, data and any illustrative material provided in this data sheet are typical and must be specifically confirmed in writing by F-tone Networks before they become applicable to any particular order or contract. In accordance with the F-tone Networks policy of continuous improvement specifications may change without notice.

The publication of information in this data sheet does not imply freedom from patent or other protective rights of F-tone Networks or others. Further details are available from any F-tone Networks sales representative.
