0-10Mb/s 单模单纤光收发一体模块
0-10M/S TTL SINGLE MODE BI-DIRECTIONAL SINGLE FIBER TRANSCEIVER

特点:
● 双波长复用单模单纤收发一体模块,发射、接收独立工作
● 发射器件工作波长可分别选用 1310nm FP 和 1550nm FP 激光器
● +3.3V /+5V 供电
● SC/FC/ST 插拔式或尾纤型光接口
● 接口电平兼容标准 TTL 电平和 CMOS 电平
● 标准 1×9 管脚封装
● 传输速率低至直流,上限速率可选,最高可达 10Mb/s

Feature:
● Single Fiber Bi-Directional SM optical Transceiver
● Transmitter section Selects 1310nm FP and 1550nm FP Laser
● Standard +3.3V /+5V Power Supply
● SC/FC/ST receptacle optical interface and pigtail optical interface
● Standard TTL data output with signal detect indication, compatible with CMOS level
● Standard 1×9 package
● Super low power consumption, applied to some special requirement
● Optional transmission bit rate with down to 0bps and up to 10Mbps

应用:
● 适用于 10Mb/s 以下的电力控制和工业控制的 RS232、RS485 等光电转换设备。

Applications:
● Applied to RS232、RS485 optical-electrical converter for electric power control and industrial control with bit
rate up to 10Mbps

  产品型号:B3/435x-31

Important Notice

Performance figures, data and any illustrative material provided in this data sheet are typical and must be specifically confirmed in writing by F-tone Networks before they become applicable to any particular order or contract. In accordance with the F-tone Networks policy of continuous improvement specifications may change without notice.

The publication of information in this data sheet does not imply freedom from patent or other protective rights of F-tone Networks or others. Further details are available from any F-tone Networks sales representative.
