0~50Mbps DWDM MINISFF Single Mode Transceiver (80Km)
Description
0~50Mbps DWDM MINISFF Single Mode Transceiver (80Km)
FEATURES
● All metal body, screw mount
● Transceiver unit with independent DWDM DFB
● Wavelength controlled within ± 0.4nm over life and temperature
● 2-Fiber MiniSFF LC Transceiver
● DC~50Mbps Data Rate
● LVDS Inputs & Outputs
● RoHs Compliance
● Single 3.3V Power Supply
● Operating case temperature: -50C to 80C
APPLICATIONS
● Low Rate Bus transmission
● Unbalanced Signal transparent transmission
Ordering Information
FTRS-DxxL2-DZ02I XX: 100GHZ ITU Grid Wavelength
|
P/No. |
Central Wavelength (nm) |
Frequency (THZ) |
Temperature (℃) |
|
FTRS-DxxL2-DZ02I |
1528.77~1563.86 |
192. 1~196. 1 |
-50~80 Industrial |
Wavelength Selection: C-band λc Wavelength Guide Pin Descriptions
|
Channel (xx) |
Wavelength (nm) |
Frequency (THZ) |
Channel (xx) |
Wavelength (nm) |
Frequency (THZ) |
|
C17 |
1563.86 |
191.70 |
C39 |
1546.12 |
193.90 |
|
C18 |
1563.05 |
191.80 |
C40 |
1545.32 |
194.00 |
|
C19 |
1562.23 |
191.90 |
C41 |
1544.53 |
194.10 |
|
C20 |
1561.42 |
192.00 |
C42 |
1543.73 |
194.20 |
|
C21 |
1560.61 |
192.10 |
C43 |
1542.94 |
194.30 |
|
C22 |
1559.79 |
192.20 |
C44 |
1542.14 |
194.40 |
|
C23 |
1558.98 |
192.30 |
C45 |
1541.35 |
194.50 |
|
C24 |
1558.17 |
192.40 |
C46 |
1540.56 |
194.60 |
|
C25 |
1557.36 |
192.50 |
C47 |
1539.77 |
194.70 |
|
C26 |
1556.55 |
192.60 |
C48 |
1538.98 |
194.80 |
|
C27 |
1555.75 |
192.70 |
C49 |
1538.19 |
194.90 |
|
C28 |
1554.94 |
192.80 |
C50 |
1537.40 |
195.00 |
|
C29 |
1554.13 |
192.90 |
C51 |
1536.61 |
195.10 |
|
C30 |
1553.33 |
193.00 |
C52 |
1535.82 |
195.20 |
|
C31 |
1552.52 |
193.10 |
C53 |
1535.04 |
195.30 |
|
C32 |
1551.72 |
193.20 |
C54 |
1534.25 |
195.40 |
|
C33 |
1550.92 |
193.30 |
C55 |
1533.47 |
195.50 |
|
C34 |
1550.12 |
193.40 |
C56 |
1532.68 |
195.60 |
|
C35 |
1549.32 |
193.50 |
C57 |
1531.90 |
195.70 |
|
C36 |
1548.51 |
193.60 |
C58 |
1531.12 |
195.80 |
|
C37 |
1547.72 |
193.70 |
C59 |
1530.33 |
195.90 |
|
C38 |
1546.92 |
193.80 |
C60 |
1529.55 |
196.00 |
|
Non-ITU |
Peak wavelength between 1528.77nm-1563.86 |
C61 |
1528.77 |
196.10 |
|
本产品为FTRS系列，仅展示部分参数，如有需要，请联系我们。
Important Notice
Performance figures, data and any illustrative material provided in this data sheet are typical and must be specifically confirmed in writing by F-tone Networks before they become applicable to any particular order or contract. In accordance with the F-tone Networks policy of continuous improvement specifications may change without notice.
The publication of information in this data sheet does not imply freedom from patent or other protective rights of F-tone Networks or others. Further details are available from any F-tone Networks sales representative.
