1×1 光开关
Description
1×1 光开关
产品介绍
Specifications
|
Parameters |
Unit |
FSW-1×1 |
|
|
Wavelength Range |
nm |
850±40 / 1300±40 |
1260 ~ 1650 |
|
Test Wavelength |
nm |
850 / 1300 |
1310 / 1550 |
|
Insertion Loss 1, 2 |
dB |
Typ: 0.5 Max: 0.8 |
Typ: 0.4 Max: 0.6 |
|
Return Loss 1, 2 |
dB |
MM ≥ 30 SM ≥ 50 |
|
|
Crosstalk 1 |
dB |
MM ≥ 65 SM ≥ 70 |
|
|
PDL |
dB |
≤0.05 |
|
|
WDL |
dB |
≤0.25 |
|
|
Repeatability |
dB |
≤±0.02 |
|
|
Operating Voltage |
V |
3.0 or 5.0 |
|
|
Durability |
Cycles |
≥ 10 Million |
|
|
Switching Time |
ms |
≤8 |
|
|
Optical Power |
mW |
≤500 |
|
|
Operating Temperature |
℃ |
-20 ~ +70 |
|
|
Storage Temperature |
℃ |
-40 ~ +85 |
|
|
Relative Humidity |
% |
5 ~ 95 |
|
|
Weight |
g |
14 |
|
|
Dimension |
mm |
(L)27.0×(W)12.6×(H)8.2 ±0.2 |
|
Ordering Information:
FSW-1×1-A-B-C-D-E-F-G
|
A |
B |
C |
D |
E |
F |
G |
|
Fiber Type |
Operating Voltage |
Switch Type |
Test Wavelength |
Tube Type |
Fiber Length (Include connector) |
Connector |
|
SM: SM, 9/125 M5:MM, 50/125 M6:MM, 62.5/125 X: Others |
3: 3V 5: 5V
|
L: Latching N: Non-latching |
850: 850nm 1310: 1310nm 1550: 1550nm 1310/1550:1310/1550nm X:Others |
25:250um 90:900um X: Others |
05: 0.5m±5cm 10: 1.0m±5cm 15: 1.5m±5cm X: Others |
OO:None FP:FC/PC FA: FC/APC SP: SC/PC SA: SC/APC STP: ST/PC LP: LC/PC LA: LC/APC X: Others |
