1.25G RJ Transceiver Module

Product Description
F-tone Networks’s FTRC-xx12-xxx-GC series of transceiver modules are the perfect solution for high -speed communication networks..These transceiver modules support data rates up to 1.25Gbps. The module is fully compliant with Small Form-Factor Transceiver.These transceiver modules provides the system designer with Telecom, Datacom, and other Fibre Channel applications.

Product Features
● VCSEL/FP/DFB Laser Diode Transmitter
● Up to 0.55Km on 62.5/125μm MMF，Up to 100 Km on 9/125μm SMF
● 3.3Vpower supply
● LC duplex optical interface
● CML Differential Inputs and CML Outputs and LVTTL signal detect
● Class 1 Laser International Safety Standard IEC 825 Compliant
● Operating case temperature range (Standard：0 to +70℃) or (Industrial： -40°C to +85°C)

Application
● Fiber Channel Switch Infrastructure
● Gigabit Ethernet Switches and Routers
● Digital Video system
● Other optic link

Module Outline Drawing（Units in mm)

Order Information

Note：
1. The suffix “M” denote MMF.
2.The suffix “-I” denote the industrial level.

本产品为FTRC系列，仅展示部分参数，如有需要，请联系我们。

注：本产品有全国产化型号可选
Important Notice

Performance figures, data and any illustrative material provided in this data sheet are typical and must be specifically confirmed in writing by F-tone Networks before they become applicable to any particular order or contract. In accordance with the F-tone Networks policy of continuous improvement specifications may change without notice.

The publication of information in this data sheet does not imply freedom from patent or other protective rights of F-tone Networks or others. Further details are available from any F-tone Networks sales representative.
