1 x 9 0~10Mbps MM Transmitter Module
Description
1 x 9 0~10Mbps MM Transmitter Module
Product Description
F-tone’s FLTX-M1300-02T series of receiver modules are the perfect solution for Low-speed communication networks.The transmitter modules support data rates up to 10Mbps. These modules are fully compliant with the Multi-sourced 1x9 protocol.The transmitter modules supplies the 5 Voltage and provides the system designer with products to implement a range of low-speed data and fiber MODEM designs at the 0 to 10Mbps rate for fiber communications.
Product Features
● Multi-sourced 1 x 9 pin packaged
● 1310nm FP Laser Transmitter
● SC/FC/ST single receptacle
● Up to 2Km with 62.5/125μm MMF
● Single 5V power supply
● TTL or LVTTL signal output
● Wave Solderable and washable with process plug inserted
● Two temperature ranges:
— 0°C to +70°C
— -40°C to +85°C for industry level
● ESD Level: 4
● Compatible with ROSH6
● MSL Level: 1
Application
● RS232/RS485/RS422 receptacle fiber transmission
● Fiber System
Module Outline Drawing
Ordering information
|
Part Number |
Product Description |
|
FLTX-M1300H-02 |
1x9-MM1310-0~10M-2KM-5V-SC; 0ºC~+70ºC |
|
FLTX-M1300H-02I |
1x9-MM1310-0~10M-2KM-5V-SC;-40 to +85°C |
|
FLTX-M1300H-02F |
1x9-MM1310-0~10M-2KM-5V-FC; 0ºC~+70ºC |
|
FLTX-M1300H-02FI |
1x9-MM1310-0~10M-2KM-5V-FC;-40 to +85°C |
|
FLTX-M1300H-02T |
1x9-MM1310-0~10M-2KM-5V-ST; 0ºC~+70ºC |
|
FLTX-M1300H-02TI FLTX-1310H-02TI |
1x9-MM1310-0~10M-2KM-5V-ST;-40 to +85°C |
注：本产品有全国产化型号可选
本产品为光模块1x9系列，仅展示部分参数，如有需要，请联系我们。
Important Notice
Performance figures, data and any illustrative material provided in this data sheet are typical and must be specifically confirmed in writing by F-tone Networks before they become applicable to any particular order or contract. In accordance with the F-tone Networks policy of continuous improvement specifications may change without notice.
The publication of information in this data sheet does not imply freedom from patent or other protective rights of F-tone Networks or others. Further details are available from any F-tone Networks sales representative.
