该光模块是一个四通道、可插拔、并行、光纤QSFP28 SR4收发模块，用于100G BASE SR4和100G以太网、InfiniBand EDR、FDR和QDR应用。此高性能模块专为数据通信和互连应用。它以100Gb/s速率在集成了四条数据通道。使用OM3光纤传输100m，每条通道可以以25.78125Gb/s的速度传输，传输距离可达70m使用OM4。该模块设计用于在多模光纤系统上运行，使用850nm波长。电气接口使用38针接触边缘型接头。该模块光纤接口使用12光纤MTP（MPO）连接器。本模块采用经验证的电路技术和光学技术，以提供可靠的长寿命、高性能服务。

产品特点
● 每通道传输速率25.78125Gbps
● 传输距离100m@ OM4 MMF
● 4通道850nm Vcsel 激光器阵列
● 4通道PIN-TIA阵列；支持热插拔
● 单MPO接口；发射接收带CDR功能
● 支持CDR关闭通过◎ 支持DDM功能
● 单3.3V电源输入
● 功耗小于2.5W
● 支持商业温度
● 4通道全双工收发模块

产品应用
● 100GBASE-SR4 100G Ethernet
● Infiniband EDR, FDR, QDR
● Other optical links

适用范围
● Compliant with SFF-8665 Specification
● Compliant with IEEE 802.3bm
● 100GBASE-SR4
● RoHS Compliant

注：本产品有全国产化型号可选
Important Notice

Performance figures, data and any illustrative material provided in this data sheet are typical and must be specifically confirmed in writing by F-tone Networks before they become applicable to any particular order or contract. In accordance with the F-tone Networks policy of continuous improvement specifications may change without notice.

The publication of information in this data sheet does not imply freedom from patent or other protective rights of F-tone Networks or others. Further details are available from any F-tone Networks sales representative
