155Mbps Single Mode MiniSFF BIDI FC Transceiver(40KM)
Description
155Mbps Single Mode MiniSFF BIDI FC Transceiver(40KM)
FEATURES
● Surface mount I/O pins for high speed signal integrity
● All metal body, screw mount
● Industrial Temp range, vibration tolerant design
● 1-Fiber Bi-Directional MiniSFF FC Transceiver
● Single 3.3V Power Supply
● Operating Temperature：
FTFC-B303-ZD / FTFC-B503-ZD : 0℃~+70℃
FTFC-B303-ZDI / FTFC-B503-ZDI : -40℃~+85℃
APPLICATIONS
● SDH/ SONET
● Fiber Channel Links
Ordering Information
|
P/No. |
Package
|
Bit Rate (Mb/s) |
Dist. (km) |
Wavelength (nm) |
Volt. (V) |
TX Power (dBm) |
RX Sens (dBm) |
Temp. (℃) |
|
FTFC-B303-ZD |
FC |
155 |
40 |
TX1310FP/RX1550 |
3.3 |
-8 to 0 |
-32 |
0 ~70 |
|
FTFC-B503-ZD |
TX1550DFB/RX1310 |
|||||||
|
FTFC-B303-ZDI |
FC |
155 |
40 |
TX1310FP/RX1550 |
3.3 |
-8 to 0 |
-32 |
-40 ~85 |
|
FTFC-B503-ZDI |
TX1550DFB/RX1310 |
本产品为FTFC系列，仅展示部分参数，如有需要，请联系我们。
Important Notice
Performance figures, data and any illustrative material provided in this data sheet are typical and must be specifically confirmed in writing by F-tone Networks before they become applicable to any particular order or contract. In accordance with the F-tone Networks policy of continuous improvement specifications may change without notice.
The publication of information in this data sheet does not imply freedom from patent or other protective rights of F-tone Networks or others. Further details are available from any F-tone Networks sales representative.
