532-1650nm大光束激光准直器
Description
532-1650nm大光束激光准直器
该准直器用于激光耦合,波长 500～1650nm 任意选择,光斑 0.35～14mm 任意,工作距离0.1~8m。
工作温度（多种温度级别可选）:
商用级：0~+7度
扩展级：-10~+80度
工业级：-40~+85度
军品级：-55~+85度
Important Notice
Performance figures, data and any illustrative material provided in this data sheet are typical and must be specifically confirmed in writing by F-tone Networks before they become applicable to any particular order or contract. In accordance with the F-tone Networks policy of continuous improvement specifications may change without notice.
The publication of information in this data sheet does not imply freedom from patent or other protective rights of F-tone Networks or others. Further details are available from any F-tone Networks sales representative.
Related Products
CWDM TO激光器
Part Number：FT-45-TOSA-1XX0-2-SM
Product Description: The Pluggable TO56 CWDM series laser diodes are 1.27μm~1.61μm Multiple Quantum Well (MQW) structured distributed-feedback(DFB) laser modules. These laser diodes are built in a pluggable TO56 package with monitoring PIN-PD for fiberoptic communication systems. These modules are ideally suitable for 2.5Gbps transmission applications. The products are Telcordia GR-468 qualified, and in compliance with RoHS requirement.
Applications:
█ Telecommunication transceivers
█ Datacom transceivers
█ Fiberoptic sensors
