6路分光设备
Description
6路分光设备
产品介绍
12个OTAP 端口（支持6路主链路双芯双向流量制复）,LC/UPC接头,19英寸 无源1U机箱。
产品特点
● 低插损,不影响数据流量包。
● 无需电源，无需IP址址，无需MAC地址,100%无源产品,性能安全可靠
● 安装和操作简单,非专业人士即可独立完成
● 12个OTAP端口,支持4路主链路串接,数据流量复制；可替代6个交换机镜象端口。
● 成本低,集成度高
产品规格
|
型号 |
FT-12TAP-1U01-A |
FT-12TAP-1U01-B |
FT-12TAP-1U01-C |
FT-12TAP-1U01-D |
|
分光比 |
80/20 |
70/30 |
60/40 |
50/50 |
|
端口配置 |
12个OTAP 端口（支持6路主链路双芯双向流量制复） |
|||
|
工作波长（nm） |
1310/1550nm |
|||
|
主链路插损(dB) |
≤1.0 |
≤1.7 |
≤2.5 |
≤3.4 |
|
复制链路插损(dB) |
≤7.7 |
≤5.7 |
≤4.5 |
≤3.4 |
|
均匀性(dB) |
≤0.8 |
|||
|
回波损耗(dB) |
≥55 |
|||
|
偏振相关损耗(dB) |
≤0.15 |
|||
|
方向性(dB) |
≥55 |
|||
|
光纤类型 |
单模SMF-28e |
|||
|
接头 |
LC/UPC |
|||
|
设备尺寸(mm) |
1U 机架 440*230*44MM |
|||
|
工作温度（℃） |
-40 ~ +85 |
|||
多模产品规格
|
型号 |
FT-12TAP-1U01-A-M3 |
FT-12TAP-1U01-B-M3 |
FT-12TAP-1U01-C-M3 |
FT-12TAP-1U01-D-M3 |
|
分光比 |
80/20 |
70/30 |
60/40 |
50/50 |
|
端口配置 |
12个OTAP 端口（支持6路主链路双芯双向流量制复） |
|||
|
工作波长（nm） |
850nm |
|||
|
主链路插损(dB) |
≤1.6 |
≤2.2 |
≤2.8 |
≤3.8 |
|
复制链路插损(dB) |
≤7.9 |
≤6.1 |
≤4.8 |
≤3.8 |
|
均匀性(dB) |
≤0.8 |
|||
|
回波损耗(dB) |
≥55 |
|||
|
偏振相关损耗(dB) |
≤0.15 |
|||
|
方向性(dB) |
≥55 |
|||
|
光纤类型 |
多模 OM3 |
|||
|
接头 |
LC/UPC |
|||
|
设备尺寸(mm) |
1U 机架 440*230*44MM |
|||
|
工作温度（℃） |
-40 ~ +85 |
|||
