FT SeasonBeam 200 Isolator
Description
FT SeasonBeam 200 Isolator
SeasonBeam Isolator proves solution to fiber laser that is required to operate in wide temperature range. With patented design, SeasonBeam isolator maintains high isolation in temperature between 0⁰C and 55⁰C to assure laser operates well at all environment temperatures. The SeasonBeam can be used alone or in combination with FT SteadiBeam technology for higher power isolators to eliminate thermal lensing effect.
| Specifications | ||
| Parameter | Unit | Value |
| Center Wavelength (λc) | nm | 1064±15nm |
| Typ. Peak Isolation | dB | 40 |
| Min. Isolation at 23℃,λc all polarization states | dB | 35 |
| Min. Isolation at all temperature,λc | dB | 30 |
| Max. Insertion Loss at 23℃,λc | dB | 0.4 |
| Max. Insertion Loss at all temperature | dB | 0.5 |
| Min. Return Loss | dB | 50 |
| Nominal Output Beam Diameter (1/e^2) | mm | 7.0 ± 0.5 |
| Beam Circularity | % | > 90 |
| M2 Degradation | % | < 10 |
| Max. Average Optical Power | W | 20 - 100 |
| Max. Peak Power for ns pulse | KW | 35 |
| Fiber Type (input port) | Specified by ordering info | |
| Operating Temperature | ℃ | 0 to +55 |
| Storage Temperature | ℃ | -20 to +70 |
Important Notice
Performance figures, data and any illustrative material provided in this data sheet are typical and must be specifically confirmed in writing by F-tone Networks before they become applicable to any particular order or contract. In accordance with the F-tone Networks policy of continuous improvement specifications may change without notice.
The publication of information in this data sheet does not imply freedom from patent or other protective rights of F-tone Networks or others. Further details are available from any F-tone Networks sales representative.
Related Products
FT Singlemode Filter WDM (980/1064)
FT Singlemode Filter WDM (980/1064)
The Filter Wavelength Division Multiplexer is based on environmentally stable thin-film filter technology. The devices combine or separate light at different wavelength in a wide wavelength range. They offer very low insertion loss, low polarization dependence, high isolation and excellent environmental stability. High power handling capability can be achieved through unique pigtail processing and high quality ft coating. These components have been extensively used in EDFAs, Raman amplifiers, WDM networks and fiber optical instruments.
PM Filter WDM (980/1064)
PM Filter WDM (980/1064)
The Polarization Maintaining Filter Wavelength Division Multiplexer provides wavelength division multiplexing while maintaining signal polarization. The components are based on environmentally stable thin-film filter technology and are characterized with high extinction ratio, low insertion loss, and high return loss. They are ideal for high speed WDM network systems.
FT 1064nm Polarization Maintaining Isolator
FT 1064nm Polarization Maintaining Isolator
The Wavelength Division Multiplexers combine or separate light at different wavelengths. They offer very low insertion loss, low polarization dependence, high isolation and excellent environmental stability. These components have been extensively used in laser marking and fiber optics instrumentation.
FT 2000 nm Faraday Rotator Mirror
FT 2000 nm Faraday Rotator Mirror
The Faraday Mirror is a passive device that provides 90 degree rotation regarding to the polarization state of the input light. The FM offers excellent performance including the lowest possible insertion loss and enviromental stability. It is used in EDFAs, fiber lasers and fiber instruments to mininize the polarization effect.
FT SteadiBeam 200 Isolator
