光波分复用模块
Description
CWDM 波分复用模块
随着信息时代的到来,数据中心升级扩容需求势在必行,通过敷设更多光纤来扩大光纤网络传输容量的方法既耗时又费力,而且会大大增加网络的投入和运营成本,但CWDM＆DWDM 复用/解复用器就可完全避免这些缺点,利用 CWDM＆DWDM 复用/解复用器的复用和
解复用技术是在现有光纤基础设施的基础上实现光纤扩容的理想解决方案.
工作温度（多种温度级别可选）:
商用级：0~+7度
扩展级：-10~+80度
工业级：-40~+85度
军品级：-55~+85度
Important Notice
Performance figures, data and any illustrative material provided in this data sheet are typical and must be specifically confirmed in writing by F-tone Networks before they become applicable to any particular order or contract. In accordance with the F-tone Networks policy of continuous improvement specifications may change without notice.
The publication of information in this data sheet does not imply freedom from patent or other protective rights of F-tone Networks or others. Further details are available from any F-tone Networks sales representative.
