拉曼光纤放大器
Description
C 波段拉曼光纤放大器
拉曼放大器采用多泵浦激光器合波及消偏技术,通过不同类型泵浦激光器的组合以及光纤类型的匹配,实现 C 波段范围内低噪声光信号放大。模块内置精心设计的驱动电路和逻辑控制电路,配合电信级的 14xx 泵浦激光器,实现高性能的输出,输出功率的稳定性由独特设计的 ATC和APPC电路得以保证。为保护设备和人身的安全,放大器内部具有多种检测和保护措施,保障产品安全、稳定运行。
|
特性
|
应用
|
工作温度（多种温度级别可选）:
商用级：0~+7度
扩展级：-10~+80度
工业级：-40~+85度
军品级：-55~+85度
Important Notice
Performance figures, data and any illustrative material provided in this data sheet are typical and must be specifically confirmed in writing by F-tone Networks before they become applicable to any particular order or contract. In accordance with the F-tone Networks policy of continuous improvement specifications may change without notice.
The publication of information in this data sheet does not imply freedom from patent or other protective rights of F-tone Networks or others. Further details are available from any F-tone Networks sales representative.
