1×N 机架式光开关

产品特征:
低损耗,高可靠性
标准配置RS232串口、以太网控制接口
模块化设计
性线路无胶

1x1 纳秒高速光开关

The NanoSpeedTM 1x1 series fiber optic on-off switches are fast shutter device featuring very low loss, fast response, and high optical power handling. This is achieved using patented non-mechanical configurations with solid-state all-crystal designs, which eliminates the need for mechanical movement and organic materials. The NS fiber-optic switch is designed to meet the most demanding switching requirements of ultra-high reliability, fast response time, and continuous switching operation. The switch is bidirectional.

1x32机械式光开关

工作温度（多种温度级别可选）:
商用级：0~+7度
扩展级：-10~+80度
工业级：-40~+85度
军品级：-55~+85度

光开关模块

1×N 光开关模块是成都北亿纤通光电科技有限公司所开发的一种具有多通道光路切换作用功能的光学器件，广泛应用于各种光通信、测试系统中。

应用范围:
光传输系统中的多路光监控
LAN 多光源/探测器自动换接、光传感多点动态监测系统
光测试系统中用于光纤、光器件、光网络和野外工程光缆测试
光器件装调

2x2机械式光开关

产品应用:
光信号上/下路
系统监控
仪器设备
光信号路由

MEMS光开关

MEMS optical switch is based on micro-electro-mechanical system (MEMS) technology,and it is widely used in OADM, OXC, system monitoring and so on. Based on the special optical design, it features excellent optical characteristics with fast switch time, low insertion loss, and high reliability. Moreover, because of its compact structure and small volume, it easy to be integrated with high density in the optical fiber communication system.
