S-Mini Analog Optical Receiver with Pigtail

S-Mini Analog Optical Receiver with Pigtail

0.0/5 rating (0 votes)

Description

Features
◆Supper-Mini size:31.3mm*17mm*10mm(L*W*H)
◆Low power consumption
◆Wide operating frequency from 10MHz to 12GHz
◆Flat frequency response
◆Single +5V Power supply
◆have optical power monitoring functions
◆Excellent EMI/EMC design
◆Integrated broadband amplifier (optional)
Applications
◆WiMAX / 4G / 5G
◆Satellite communications
◆Mobile backhaul
◆GPS signal transport
◆All-Digital QAM network
◆Data and video distribution
◆Distributed antenna system 3434343434






Important Notice

Performance figures, data and any illustrative material provided in this data sheet are typical and must be specifically confirmed in writing by F-tone Networks before they become applicable to any particular order or contract. In accordance with the F-tone Networks policy of continuous improvement specifications may change without notice.

The publication of information in this data sheet does not imply freedom from patent or other protective rights of F-tone Networks or others. Further details are available from any F-tone Networks sales representative.
