标准光模块
100G QSFP28 CWDM4 光模块
Description
该模块是一个四通道、可插拔、并行、光纤QSFP28 FR4光模块，用于100GBASEFR4和100G以太网、InfiniBand EDR、FDR和QDR应用。此高性能模块专为数据通信和互连应用。它以100Gb/s的速度在每个方向上集成了四条数据通道。每个通道可以25.78125Gb/s的速度运行，传输距离可达2km。
产品特点
● 支持热插拔
● 传输速率103.1Gbps
● 功耗小于3.5W
● 符合RoHS标准
● 支持商业温度
● 单3.3V 电源输入
● FEC SMF, 损耗5dB
● 4x25Gb/s CWDM 激光器
● 4x25G retimed 电接口
● 双LC光接口
● I2C 管理接口
产品应用
● 100GBASE-FR4 100G Ethernet
● Infiniband EDR, FDR, QDR
● Other optical links
适用标准
● Compliant with SFF-8665 Specification
● Compliant with IEEE 802.3bm
● 100GBASE-FR4
● RoHS Compliant
注：本产品有全国产化型号可选
Important Notice
Performance figures, data and any illustrative material provided in this data sheet are typical and must be specifically confirmed in writing by F-tone Networks before they become applicable to any particular order or contract. In accordance with the F-tone Networks policy of continuous improvement specifications may change without notice.
The publication of information in this data sheet does not imply freedom from patent or other protective rights of F-tone Networks or others. Further details are available from any F-tone Networks sales representative
