标准光模块
10Gbps MiniSFF CWDM Transceiver(10km)
Description
10Gbps MiniSFF CWDM Transceiver(10km)
FEATURES
● Surface mount I/O pins for high speed signal integrity
● All metal body, solder or screw mount options
● Industrial Temp range, vibration tolerant design
● LVTTL Signal Detection Output
● Up to 10km links
● 2-Fiber MiniSFF LC Transceiver
● 1270～1610nm CWDM Cooled DML transmitter,APD photo-detector
● Single 3.3V Power Supply
● Operating case temperature:
FT-95-RS-Cxx1X-DZ04 : 0 ℃to 70℃
FT-95-RS-Cxx1X-DZ04I : -40 ℃to 85℃
APPLICATIONS
● CWDM optic fiber transmission system
Ordering Information
FT-95-RS-Cxx1X-DZ04 XX: 1270～1610nm CWDM Wavelength
|
P/No. |
Temp. (℃) |
Wavelength (nm) |
Dist. (km) |
TX Power (dBm) |
RX Sens (dBm) |
Package |
Bit Rate (Gb/s) |
Volt. (V) |
|
FT-95-RS-C271X-DZ04 |
0 ~70 |
1270 |
10 |
-4 to +3 |
-23 |
LC |
10 |
3.3 |
|
FT-95-RS-C291X-DZ04 |
0 ~70 |
1290 |
||||||
|
FT-95-RS-C311X-DZ04 |
0 ~70 |
1310 |
||||||
|
FT-95-RS-C331X-DZ04 |
0 ~70 |
1330 |
||||||
|
FT-95-RS-C351X-DZ04 |
0 ~70 |
1350 |
||||||
|
FT-95-RS-C371X-DZ04 |
0 ~70 |
1370 |
||||||
|
FT-95-RS-C391X-DZ04 |
0 ~70 |
1390 |
||||||
|
FT-95-RS-C411X-DZ04 |
0 ~70 |
1410 |
||||||
|
FT-95-RS-C431X-DZ04 |
0 ~70 |
1430 |
||||||
|
FT-95-RS-C451X-DZ04 |
0 ~70 |
1450 |
||||||
|
FT-95-RS-C471X-DZ04 |
0 ~70 |
1470 |
||||||
|
FT-95-RS-C491X-DZ04 |
0 ~70 |
1490 |
||||||
|
FT-95-RS-C511X-DZ04 |
0 ~70 |
1510 |
||||||
|
FT-95-RS-C531X-DZ04 |
0 ~70 |
1530 |
||||||
|
FT-95-RS-C551X-DZ04 |
0 ~70 |
1550 |
||||||
|
FT-95-RS-C571X-DZ04 |
0 ~70 |
1570 |
||||||
|
FT-95-RS-C591X-DZ04 |
0 ~70 |
1590 |
||||||
|
FT-95-RS-C611X-DZ04 |
0 ~70 |
1610 |
FT-95-RS-Cxx1X-DZ04I XX: 1270～1610nm CWDM Wavelength
|
P/No. |
Temp. (℃) |
Wavelength (nm) |
Dist. (km) |
TX Power (dBm) |
RX Sens (dBm) |
Package |
Bit Rate (Gb/s) |
Volt. (V) |
|
FT-95-RS-C271X-DZ04I |
-40~85 |
1270 |
10 |
-4 to +3 |
-23 |
LC |
10 |
3.3 |
|
FT-95-RS-C291X-DZ04I |
-40~85 |
1290 |
||||||
|
FT-95-RS-C311X-DZ04I |
-40~85 |
1310 |
||||||
|
FT-95-RS-C331X-DZ04I |
-40~85 |
1330 |
||||||
|
FT-95-RS-C351X-DZ04I |
-40~85 |
1350 |
||||||
|
FT-95-RS-C371X-DZ04I |
-40~85 |
1370 |
||||||
|
FT-95-RS-C391X-DZ04I |
-40~85 |
1390 |
||||||
|
FT-95-RS-C411X-DZ04I |
-40~85 |
1410 |
||||||
|
FT-95-RS-C431X-DZ04I |
-40~85 |
1430 |
||||||
|
FT-95-RS-C451X-DZ04I |
-40~85 |
1450 |
||||||
|
FT-95-RS-C471X-DZ04I |
-40~85 |
1470 |
||||||
|
FT-95-RS-C491X-DZ04I |
-40~85 |
1490 |
||||||
|
FT-95-RS-C511X-DZ04I |
-40~85 |
1510 |
||||||
|
FT-95-RS-C531X-DZ04I |
-40~85 |
1530 |
||||||
|
FT-95-RS-C551X-DZ04I |
-40~85 |
1550 |
||||||
|
FT-95-RS-C571X-DZ04I |
-40~85 |
1570 |
||||||
|
FT-95-RS-C591X-DZ04I |
-40~85 |
1590 |
||||||
|
FT-95-RS-C611X-DZ04I |
-40~85 |
1610 |
本产品为FT-95-系列，仅展示部分参数，如有需要，请联系我们。
Important Notice
Performance figures, data and any illustrative material provided in this data sheet are typical and must be specifically confirmed in writing by F-tone Networks before they become applicable to any particular order or contract. In accordance with the F-tone Networks policy of continuous improvement specifications may change without notice.
The publication of information in this data sheet does not imply freedom from patent or other protective rights of F-tone Networks or others. Further details are available from any F-tone Networks sales representative.
