超小型18CH-Mini-CCWDM波分复用器
Description
18CH-Mini-CCWDM
1, Profile View
2, Optic Specifications
|
Items |
18CH |
|
Operating wavelength |
1260-1620nm |
|
Channel spacing |
20nm |
|
Passband |
±6.5nm |
|
Insertion Loss |
≤2.5 dB |
|
Adjacent ChannelIsolation |
≥28dB |
|
Non Adjacent ChannelIsolation |
≥45dB |
|
Return Loss |
≥45 dB ( for UPC)、≥50 dB ( for APC) |
|
PDL |
≤0.2 dB |
|
Ripple |
≤0.5 dB |
|
Directivity |
≥50dB |
|
Power handling |
300mw
|
|
Package Dimension |
L44xW41xH11mm |
3, Absolute maximum ratings
|
NO |
Parameter |
specification |
units |
note |
|
3.1 |
Operation temperature |
-25～75 |
℃ |
|
|
3.2 |
Storage temperature |
-40～85 |
℃ |
|
|
3.3 |
Operating humidity |
5～90 |
%RH |
|
|
3.4 |
Tensile strength |
＞5 |
N |
|
4, Pigtail and connector
|
NO |
Parameter |
specification |
units |
note |
|
4.1 |
Fiber type |
SMF-28E Ultra |
|
All ports |
|
4.2 |
Pigtail length |
Customer defined |
m |
All ports |
|
4.3 |
Connector type |
Customer defined |
|
All ports |
|
4.4 |
Fiber color |
white |
|
All ports |
Important Notice
Performance figures, data and any illustrative material provided in this data sheet are typical and must bespecifically confirmed in writing by F-tone Networks before they become applicable to any particular order orcontract. In accordance with the F-tone Networks policy of continuous improvement specifications may changewithout notice.
The publication of information in this data sheet does not imply freedom from patent or other protective rights of F-tone Networks or others. Further details are available from any F-tone Networks sales representative.
