标准光模块
4.25Gbps单模 MiniSFF单纤双向光收发一体模块
Description
产品特征
●纯国产零部件
●高可靠、全金属外壳、抗振动设计
●3.3V单电源供电
●宽工作温度范围
●MiniSFF封装,FC接口
●传输距离:10km
●SD输出告警
●工作温度:
FTFC-B1342-10I-GC FTFC-B1542-101-GC: 0C.+70C
FTFC-B1342-10l-GCI FTFC-B1542-10I-GCI: 40C.+85C
产品应用
●以太网、Sonet/SDH、交换机等数字光纤通信系统
●光纤通信链路
Important Notice
Performance figures, data and any illustrative material provided in this data sheet are typical and must be specifically confirmed in writing by F-tone Networks before they become applicable to any particular order or contract. In accordance with the F-tone Networks policy of continuous improvement specifications may change without notice.
The publication of information in this data sheet does not imply freedom from patent or other protective rights of F-tone Networks or others. Further details are available from any F-tone Networks sales representative.
