850nm多模机械式可调衰减器
Description
850nm多模机械式可调衰减器
产品特点:
● 宽衰减范围
● 高精度
● 低插入损耗
● 高回损
● 波长/偏振不敏感性
● 尺寸紧凑
● 性能稳定可靠
● 环境稳定性好
应用领域:
● 传感器
● 功率均衡器
● 实验室测试
● 增益平坦滤波器
● 光传输系统
工作温度（多种温度级别可选）:
商用级：0~+7度
扩展级：-10~+80度
工业级：-40~+85度
军品级：-55~+85度
Important Notice
Performance figures, data and any illustrative material provided in this data sheet are typical and must be specifically confirmed in writing by F-tone Networks before they become applicable to any particular order or contract. In accordance with the F-tone Networks policy of continuous improvement specifications may change without notice.
The publication of information in this data sheet does not imply freedom from patent or other protective rights of F-tone Networks or others. Further details are available from any F-tone Networks sales representative.
