产品简介：应用于硅光方案的光模块，实现与硅光芯片的垂直耦合

北亿纤通专业研发生产:90° 折弯FA, 是一家专业的90° 折弯FA厂家,具有优质的90° 折弯FA品质,有很好的90° 折弯FA价格,90° 折弯FA海量交付给国防、军工、航空、航天、兵器、舰船、雷达、电子、核工业、军事、电力、铁路、医疗、交通、通信、电信、政府、国防科技工业系统内大专院校及科研院所

产品描述

F-tone Networks 90deg Bending Fiber Array is fabricated with F-tone Networks self-made high precision Y-Groove and ribbon fiber. By special bend, assembly and polish process, the 90deg FA get low insertion loss, high accuracyfiber core pitch and 2000hours reliability qualified, Compact package with height less than 3.8mm can be customized for Si-Photonics transceiver

Features:
●Ultra flexible optical fiber
●2000h reliability test qualified.
●High fiber core position accuracy.
●Compact package dimension
Applicalion:
●100G/400G transcelver by Si-Photonics
●COBO
Standard:
●Substances according to RoHS2011/65/EU
●Product is qualified to Telcordia GR-1221-CORE

Important Notice

Performance figures, data and any illustrative material provided in this data sheet are typical and must be specifically confirmed in writing by F-tone Networks before they become applicable to any particular order or contract. In accordance with the F-tone Networks policy of continuous improvement specifications may change without notice.

The publication of information in this data sheet does not imply freedom from patent or other protective rights of F-tone Networks or others. Further details are available from any F-tone Networks sales representative.
