多模 MEMS 光衰减器
Description
多模迷你VOA
多模 VOA 是迷你VOA系列中支持多模激光衰减特殊的VOA产品. 基于单模VOA的基本设计，在设计和制造过程中给予了特殊的考虑，以在多模式操作中实现期望的性能。MMVOA是用于优异性能的多模激光系统中的关键部件。
特征:
● 采用TO46封装的微型设计
● 完全密封
● 低插入损耗(IL) ? 高衰减精度
● 低功耗
● 快速响应
● 高光功率承受力
● 兼容Telcordia GR-1209 & GR-1221
工作温度（多种温度级别可选）:
商用级：0~+7度
扩展级：-10~+80度
工业级：-40~+85度
军品级：-55~+85度
Important Notice
Performance figures, data and any illustrative material provided in this data sheet are typical and must be specifically confirmed in writing by F-tone Networks before they become applicable to any particular order or contract. In accordance with the F-tone Networks policy of continuous improvement specifications may change without notice.
The publication of information in this data sheet does not imply freedom from patent or other protective rights of F-tone Networks or others. Further details are available from any F-tone Networks sales representative.
