FT 830nm Isolator, Single Stage
Description
FT 830nm Isolator, Single Stage
The 830nm High Power Polarization Insensitive Isolator is characterized with low insertion loss, high isolation, high power handling, high return loss, excellent environmental stability and reliability. It is ideal for fiber laser and instrumentation applications.
|
Specifications |
|||
|
Parameter |
Unit |
Grade P |
Grade A |
|
Center Wavelength (λc) |
nm |
830 or specify |
|
|
Max. Polarization Dependent Loss |
dB |
0.15 |
0.2 |
|
Min. Isolation, λc, 23 ℃, all polarization states |
dB |
22 |
20 |
|
Typ. Insertion Loss, 23 ℃ |
dB |
1.3 |
1.6 |
|
Max. Insertion Loss, 23 ℃ |
dB |
1.6 |
1.8 |
|
Min. Return Loss (Input/Output) |
dB |
50/50 |
45/45 |
|
Max. Optical Power (Continuous Wave) |
mW |
500 |
|
|
Max. Tensile Load |
N |
5 |
|
|
Fiber Type |
HI 780 SM fiber |
||
|
Operating Temperature |
℃ |
10 to + 50 |
|
|
Storage Temperature |
℃ |
0 to + 60 |
|
mportant Notice
Performance figures, data and any illustrative material provided in this data sheet are typical and must be specifically confirmed in writing by F-tone Networks before they become applicable to any particular order or contract. In accordance with the F-tone Networks policy of continuous improvement specifications may change without notice.
The publication of information in this data sheet does not imply freedom from patent or other protective rights of F-tone Networks or others. Further details are available from any F-tone Networks sales representative.
