标准光模块
J599 A8系列光纤连接器
Description
产品描述
● 接口尺寸符合GJB599A(MIL-DTL-38999)Ⅲ，性能符合ARINC801标准
● 外壳体可选用不同材料及镀层适应不同环境要求
● 五键定位，有盲插和防错插功能，三头螺纹快速连接，并带有防松脱结构
● 采用陶瓷插针和套管实现接触件精密对接
● 有多种尾部变化形式可选
● 有转接插座（可选气密封）形式，摆脱光缆束缚
注：本产品有全国产化型号可选
Important Notice
Performance figures, data and any illustrative material provided in this data sheet are typical and must be specifically confirmed in writing by F-tone Networks before they become applicable to any particular order or contract. In accordance with the F-tone Networks policy of continuous improvement specifications may change without notice.
The publication of information in this data sheet does not imply freedom from patent or other protective rights of F-tone Networks or others. Further details are available from any F-tone Networks sales representative.
