增益平坦光纤滤波器
Description
增益平坦光纤滤波器
Product description
The GFF device is based on proven thin-film filter
technology and is used to compensate for the uneven gain
amplification at different DWDM channel by Er-doped fiber
amplifier (EDFA).
Product Features
Accurate Gain Profile Matching
Low Insertion loss error function
Flat spectral gain
Excellent thermal stability
Important Notice
Performance figures, data and any illustrative material provided in this data sheet are typical and must be specifically confirmed in writing by F-tone Networks before they become applicable to any particular order or contract. In accordance with the F-tone Networks policy of continuous improvement specifications may change without notice.
The publication of information in this data sheet does not imply freedom from patent or other protective rights of F-tone Networks or others. Further details are available from any F-tone Networks sales representative.
