800G Twin-port OSFP 2x400Gb/s Multimode 2xSR4 100m Transceiver

Features
● 800G 2xSR4 multimode transceiver
● 8-channels of 100G-PAM4 electrical modulation
● Two ports of 4-channel 100G-PAM4 optical modulation
● Supports two straight 400Gb/s or two 1:2 splitter fiber cables for 200Gb/s
● Finned-top OSFP for air-cooled switches
● 850nm VCSEL
● Maximum reach: 100m using OM4 fiber
● Two MPO-12/APC optical connectors
● 14 Watts max power
● Single 3.3V power supply
● Class 1 laser safety
● Hot pluggable, RoHS compliant
● CMIS 4.0 compliant
● Case temperature range 0°C to +70°C

Description
FTCO-8H-SR4 is an Eight-Channel, Parallel, Pluggable, Fiber-Optic OSFP for 800Gigabit Ethernet applications.This transceiver is a high performance module for shortrange data communication and interconnect application. Itintegrates eight data lanes in each direction with 8x53.125GBd. The length of OSFP SR8 is up to 70 meters over OM3MMF or 100 meters over OM4 MMF. This module is designed to operate over multimode fiber systems using a nominalwavelength of 850nm.
The transceiver combinations guarantee optimal operation. Rigorous production testing ensures the best out-of-the-box installation experience, performance, and durability.

北亿纤通 | F-tone Networks
企业邮箱：sales@f-tone.com
企业网站：www.f-tone.com
企业网站：www.sfpgmk.com
企业电话：028-85255257
企业传真：028-85977702

注：本产品有全国产化型号可选
本产品仅展示部分参数(VS)，如有需要，请联系我们。

Important Notice

Performance figures, data and any illustrative material provided in this data sheet are typical and must be specifically confirmed in writing by F-tone Networks before they become applicable to any particular order or contract. In accordance with the F-tone Networks policy of continuous improvement specifications may change without notice.

The publication of information in this data sheet does not imply freedom from patent or other protective rights of F-tone Networks or others. Further details are available from any F-tone Networks sales representative.
