2×5 SFF 4.25Gbps MM Transceiver Module

Product Description
F-tone' s FTAF-8542-02I series of transceiver modules are the perfect solution for high -speed communication networks.These transceiver modules support data rates up to 4.25Gbps. The module is fully compliant with the 2×5 standard package defined by the Small Form Factor Multi-Sourcing Agreement (MSA).These transceiver modules provides the system designer with Telecom, Datacom, and other Fibre Channel applications.

Product Features
● 850nm VCSEL Transmitter
● Distance up to 300m at MM Fiber
      300m links with OM3 MMF Cables
      82m links with OM2 MMF Cables
      33m links with OM1 MMF Cables
● 3.3V power supply
● LC duplex optical interface
● CML Differential Inputs 、CML Outputs and ( LV)TTL signal detect
● Class 1 Laser International Safety Standard IEC 825 Compliant
● Operating case temperature range (Standard：0 to +70℃) or (Industrial： -40°C to +85°C)

Application
● Fiber Channel Switch Infrastructure
● Other optic links

Order Information

 Note：
1. The suffix “M” denote MMF.
2. The suffix “-I” denote the industry level

本产品为FTAF系列，仅展示部分参数，如有需要，请联系我们。
Important Notice

Performance figures, data and any illustrative material provided in this data sheet are typical and must be specifically confirmed in writing by F-tone Networks before they become applicable to any particular order or contract. In accordance with the F-tone Networks policy of continuous improvement specifications may change without notice.

The publication of information in this data sheet does not imply freedom from patent or other protective rights of F-tone Networks or others. Further details are available from any F-tone Networks sales representative.
