10Gbps MiniSFF CWDM Transceiver（单收）
Description
10Gbps MiniSFF CWDM Transceiver（单收）
FEATURES
● Surface mount I/O pins for high speed signal integrity
● All metal body, solder or screw mount options
● Industrial Temp range, vibration tolerant design
● Up to 10km links
● 2-Fiber MiniSFF LC Transceiver
● 1271～1611nm CWDM Cooled DML transmitter
● Multimode 850nm Receiver
● Single 3.3V Power Supply
● Operating case temperature:
FT-95-RS-CxxR851X-02D : 0℃~+70℃
FT-95-RS-CxxR851X-02DI : -40℃~+85℃
APPLICATIONS
● CWDM optic fiber transmission system
Ordering Information
FT-95-RS-CxxR851X-02D XX: 1271～1611nm CWDM Wavelength
|
P/No. |
Temp. (℃) |
Wavelength (nm) |
Dist. (km) |
TX Power (dBm) |
RX Sens (dBm) @850nm |
Package |
Bit Rate (Gb/s) |
Volt. (V) |
|
FT-95-RS-C27R851X-02D |
0~70 |
1271 |
10 |
-3 to +2 |
-10 |
LC |
10 |
3.3 |
|
FT-95-RS-C29R851X-02D |
0~70 |
1291 |
||||||
|
FT-95-RS-C31R851X-02D |
0~70 |
1311 |
||||||
|
FT-95-RS-C33R851X-02D |
0~70 |
1331 |
||||||
|
FT-95-RS-C35R851X-02D |
0~70 |
1351 |
||||||
|
FT-95-RS-C37R851X-02D |
0~70 |
1371 |
||||||
|
FT-95-RS-C39R851X-02D |
0~70 |
1391 |
||||||
|
FT-95-RS-C41R851X-02D |
0~70 |
1411 |
||||||
|
FT-95-RS-C43R851X-02D |
0~70 |
1431 |
||||||
|
FT-95-RS-C45R851X-02D |
0~70 |
1451 |
||||||
|
FT-95-RS-C47R851X-02D |
0~70 |
1471 |
||||||
|
FT-95-RS-C49R851X-02D |
0~70 |
1491 |
||||||
|
FT-95-RS-C51R851X-02D |
0~70 |
1511 |
||||||
|
FT-95-RS-C53R851X-02D |
0~70 |
1531 |
||||||
|
FT-95-RS-C55R851X-02D |
0~70 |
1551 |
||||||
|
FT-95-RS-C57R851X-02D |
0~70 |
1571 |
||||||
|
FT-95-RS-C59R851X-02D |
0~70 |
1591 |
||||||
|
FT-95-RS-C61R851X-02D |
0~70 |
1611 |
FT-95-RS-CxxR851X-02DI XX: 1271～1611nm CWDM Wavelength
|
P/No. |
Temp. (℃) |
Wavelength (nm) |
Dist. (km) |
TX Power (dBm) |
RX Sens (dBm) @850nm |
Package |
Bit Rate (Gb/s) |
Volt. (V) |
|
FT-95-RS-C27R851X-02DI |
-40~85 |
1271 |
10 |
-3 to +2 |
-10 |
LC |
10 |
3.3 |
|
FT-95-RS-C29R851X-02DI |
-40~85 |
1291 |
||||||
|
FT-95-RS-C31R851X-02DI |
-40~85 |
1311 |
||||||
|
FT-95-RS-C33R851X-02DI |
-40~85 |
1331 |
||||||
|
FT-95-RS-C35R851X-02DI |
-40~85 |
1351 |
||||||
|
FT-95-RS-C37R851X-02DI |
-40~85 |
1371 |
||||||
|
FT-95-RS-C39R851X-02DI |
-40~85 |
1391 |
||||||
|
FT-95-RS-C41R851X-02DI |
-40~85 |
1411 |
||||||
|
FT-95-RS-C43R851X-02DI |
-40~85 |
1431 |
||||||
|
FT-95-RS-C45R851X-02DI |
-40~85 |
1451 |
||||||
|
FT-95-RS-C47R851X-02DI |
-40~85 |
1471 |
||||||
|
FT-95-RS-C49R851X-02DI |
-40~85 |
1491 |
||||||
|
FT-95-RS-C51R851X-02DI |
-40~85 |
1511 |
||||||
|
FT-95-RS-C53R851X-02DI |
-40~85 |
1531 |
||||||
|
FT-95-RS-C55R851X-02DI |
-40~85 |
1551 |
||||||
|
FT-95-RS-C57R851X-02DI |
-40~85 |
1571 |
||||||
|
FT-95-RS-C59R851X-02DI |
-40~85 |
1591 |
||||||
|
FT-95-RS-C61R851X-02DI |
-40~85 |
1611 |
本产品为FT-95-系列，仅展示部分参数，如有需要，请联系我们。
Important Notice
Performance figures, data and any illustrative material provided in this data sheet are typical and must be specifically confirmed in writing by F-tone Networks before they become applicable to any particular order or contract. In accordance with the F-tone Networks policy of continuous improvement specifications may change without notice.
The publication of information in this data sheet does not imply freedom from patent or other protective rights of F-tone Networks or others. Further details are available from any F-tone Networks sales representative.
