J599/MT系列光纤连接器
Description
产品描述
● 符合GJB599A（MIL-DTL-38999)Ⅲ系列接口
● 五键定位，具有盲插和防错差及抗振功能
● 三头螺纹快速连接，并带有防松脱结构
● 外壳体可选用不同材料及镀层适应不同环境要求
● 接触件为M12、M24类，采用标准MT接口，性能可靠、操作简单、集成度高，产品可实现12路、24路、48路、96路等高密度光信号传输
● 采用三级引导限位；壳体、导销、MT导针
注：本产品有全国产化型号可选
Important Notice
Performance figures, data and any illustrative material provided in this data sheet are typical and must be specifically confirmed in writing by F-tone Networks before they become applicable to any particular order or contract. In accordance with the F-tone Networks policy of continuous improvement specifications may change without notice.
The publication of information in this data sheet does not imply freedom from patent or other protective rights of F-tone Networks or others. Further details are available from any F-tone Networks sales representative.
