标准光模块
J599系列光纤连接器
Description
产品描述
● 符合GJB599A（MIL-DTL-38999)Ⅲ系列接口
● 五键定位，具有盲插和防错差及抗振功能
● 三头螺纹快速连接，并带有防松脱结构
● 连接器损耗小、可靠性高；具有防水、防尘、耐腐蚀等特点
● 产品适用于海洋舰船设备通信、机载设备、酸碱、盐酸、潮湿等 恶劣环境、军用通信及室外恶劣环境通讯
注：本产品有全国产化型号可选
Important Notice
Performance figures, data and any illustrative material provided in this data sheet are typical and must be specifically confirmed in writing by F-tone Networks before they become applicable to any particular order or contract. In accordance with the F-tone Networks policy of continuous improvement specifications may change without notice.
The publication of information in this data sheet does not imply freedom from patent or other protective rights of F-tone Networks or others. Further details are available from any F-tone Networks sales representative.
